Multiquip GA6REA
Electric Start 6.0 kW Generator
Sales Flyer for
Multiquip
Generators
Multiquip GA6REA Genratora
ONLY
see GA6HR
At Cessco
This portable generator is your best option
when the job demands a power source versatile
enough to handle changing requirements.
Equipped with electric start this unit is at home
on the job or on service trucks.
  • Twin duplex receptacles and three twist-lock receptacles for job site versatility
  • 100% copper windings for maximum conductivity
  • Alternator design eliminates maintenance by removing brushes and slip rings
  • Heavy-duty 1-inch (25 mm) steel pipe frame and shock mounts protect the
    generator
  • Includes folding lifting bale as standard equipment
  • Powered by an 11-hp Robin engine with low-oil shutdown and automatic idle
    control.
UNIT SPECIFICATIONS
Alternator design
Brushless
Frequency
60 hz
Phase voltage
Single phase
Voltage
120V / 240V
Sound level at
30 ft.
81 dBA
Fuel Tank
capacity
5 Gal / 19 L
DIMENSIONS & WEIGHTS
Overall Lenght
26.5 in. /
67.31 cm
Overall Width
22.25 in. /
56.515 cm
Overall Height
22.5 in. /
57.15 cm
Shipping
Dimensions
(standard)
(metric)
27 x 24 x
26.5in
66 X 61 X
67 cm
Operating
Weight
204 lb / 92.5 kg
Shipping Weight
220 lb / 100 kg
Power Generation

Max
Continuous
Watts
6000
5000
Amps at 120V
50.0
41.6
Amps at 240V
25
20.8
Receptacles & Circuit Breakers
Main Circuit Breaker
21 A
Number of Poles
2
1 Receptacle Each
L5-20R 125V T-Lock 20A
L5-30R 125V T-Lock 30A
L14-20R 125/250V T-Lock 20A
2 Receptacle Each
5-20R 125V GFCI 20A
FREE Ground Shipping - (Most Continental U.S. Locations)
Robin
Engine Specs:
11 Hp
Recoil / Electric Start
Gasoline
