ST2010TCUL Pump Multiquip ST2010TCUL
2 Inch Submersible Trash Pump with 32' Power Cord
Multiquip Pumps Include:  Free Ground Freight*
The ST2010TCUL is Multquip's largest
trash submersible pump. A 1-inch capacity
for solids means reliable dewatering in
sump and construction applications.
Model #
Discharge
Motor
Price
ST2010TCUL
2"
110Volt
Single Phase
(standard)
$939.95
----- Options -----
HD250
2 Inch Discharge Hose - 50' Long
    $100.00
HDQ250
2 Inch Quick Disconnect
Discharge Hose - 50' Long
    $125.00
To order with options call toll free: 1-800-882-4959
Please ask for "Internet Sales"
Use this pump curve to determine the flow rate of the ST2010TCUL pumps for any given
elevation (head).  For example if you need to pump to a height of 15 feet, this pump will
move approximately 85 gallons per minute.
ST2010TCUL Pump Curve
ST2010TCUL Features:
  1. Pump solids up to 1"
  2. Corrosion-free stainless steel
    hardware
  3. Pumps up to 95 gallons per
    minute (360 liters)
  4. Maximum head of 45 feet
    (13.7 meters)
  5. Powered by a 1Hp, 110Volt
    motor.
  6. UL/CSA Approved
 ST2010TCUL Pump
ST2010TCUL
Unit Specifications
Impeller
Type
Neoprene rubber
over cast-iron
Impeller
Disc Size
2"
51mm
Total
Head
45 ft
13.7 m
Water
Capacity
95 gpm
360 lpm
ST2010TCUL
Electrical
Specifications
Power
1 Hp
0.75 kW
Phase
Single
Voltage
110 V
Starting
Amperage
53 A
Running
Amperage
9.4 A
Cable
Length
50 ft
15.2m
ST2010TCUL
Dimensions &
Weights
Pump
Diameter
10.3
inches
267 mm
Overall
Height
22.7
inches
576 mm
Operating
Weight
77 lbs.
35 kg
Heavily debris-laden water calls for rugged pumps. Submersible trash
pumps are equipped with a 2' discharge port and easily handle solids
up to one inch in diameter. A vortex action discharges solids away
from the cast iron multi-vane impeller to prevent clogging.
Quantities limited to available stock.  Prices subject to change without website update.
