Specify Blade Guard Size and Power Source for price and availability quotes.

Features and Benefits:

• Screw feed raise/lower with optional power raise/lower
• Positive gear drive to rear axle via Eaton hydrostatic transmission
• 2 position tilt handle bars
• Rigid high strength 3/16" steel box frame with heavy bar reinforcement
• Hydraulic raise/lower offered on all models
• Maximum cutting depth of 10-3/8" with 26" model

Specifications

Maximum depth of cut with a 14" blade	4-5/8"
Maximum depth of cut with a 20" blade	7-3/8"
Maximum depth of cut with a 26" blade	10-3/8"
Blade shaft RPM	Varies
Blade shaft diameter	1-1/2"
Arbor size:	1" with drivepin
Blade shaft drive:	4 belt thru 25Hp 5 belt for 27Hp
Blade mounting	Right or left Right side only on 26" Model 5800599
Transmission	Eaton Model 6
Drive speed	0-130 feet/minute
Fuel capacity	5 Gallons
Electrict start (18-23 Hp models)	Standard
Low oil alert:	Standard
Tach/Hour meter (18-23 Hp models)	Standard
