Specify Blade Guard Size and Power Source for price and availability quotes.

Features and Benefits:

• Large 74 HP Deutz Turbo Diesel engine
• Excellent for bridge deck and parapet sawing
• Forward positioned motor for more weight on the blade where it is
  needed and less on the operator
• Extra heavy duty, reinforced single piece fram, designed specifically for the Deutz engine.
• 4-Stage air filter
• Turbo charged diesel engine for longer life and lower maintenance

Specifications

Maximum depth of cut with a 14" blade	4-1/2"
Maximum depth of cut with a 20" blade	7-1/2"
Maximum depth of cut with a 26" blade	10-1/2"
Maximum depth of cut with a 30" blade	11-3/4"
Maximum depth of cut with a 36" blade	14-3/4"
Maximum depth of cut with a 42" blade	16-3/4"
Blade shaft diameter	1-3/4"
Arbor size:	1" with drivepin
Blade shaft drive:	10 Belts
Blade mounting	Right or left
Blade raise & lower	Electro-hydraulic pump
Transmission	Eaton Model 10
Drive speed	0-200 feet/minute
Fuel capacity	9 Gallons
Air filter	4 stage
