Frame Components |
1/4" Thick Base Plate & Frame Rails |
3/16" Thick Upright Side Panels |
10" x 3" Rear Wheels Secured with Trantorque Bushings |
6" x 2" Front Roller Bearing Wheels |
|
Blade Drive |
6 Groove 3V Cross Section Sheaves |
(2) 3 Groove Banded Belts |
|
Engine and Related Components |
Belt Driven High Output 10" Diameter Fan Running @ 4000 RPM |
Sucker Fan draws air through radiator from the cleaner side of the saw and discharges at the right side of saw |
Radiator is totally shrouded and ducted through 10" diameter flex hose |
Air cleaner is a linear design with the turbo pre-cleaner in line instead of the standard 90-degree - less restriction and increased efficiency |
Linear slide belt tension method with large 3/4" Acme thread for easy adjustment |
|
Wheel Drive |
Proven Peerless Differential with Eaton transmission |
Prositraction is provided via friction from large 2" diameter cold formed splines for maximum traction without tire damage |
Mechanical positraction incorporates a turnbuckle coupling nut for quick fine tension adjustment |
|
Controls |
Single lever - cable operated friction speed controller with integrated raise and lower buttons |
Easy access lowering speed hydraulic control valve |
Water valve mounted next to speed control for easy access |
Depth indicator is easily accessed for use and maintenance |
Electronic water temperature is standard |
Engine tachometer is standard |
 |
