Air Filtration: |
Duel element with
rotating vane pre-cleaner |
Fuel Tank Capacity: |
20 gallons with sending unit
for gauge |
Hydraulic System: |
Hydrostatic wheel drive
with seat actuated shutdown |
Steering: |
Hydraulically controlled
rotary actuator |
Hydraulic Tank Capacity: |
10 gallon tank with suction
and return filters |
Max. Blade Capacity: |
20" |
Max. Cutting Depth: |
7" with a 20" blade |
Blade Shaft Diameter: |
2" |
Blade Shaft Bearings: |
Roller bearing pillow blocks |
Blade Drive Belts: |
(10) 3V Belts (2 sets of 5) |
Blade Raise/Lower Mechanism: |
Electric over hydraulic
system - 12 VDC |
Frame: |
2" x 4" x .188 wall tubing |
Wheels (2 front, 1 rear): |
14" diameter wheels
x 5” wide tires |
Wheel Bearings, Front: |
Sealed front bearings
to eliminate greasing |
Travel Speed - Forward/Reverse: |
0-375 feet per minute by hydraulically driven rear wheel |
Depth Stop: |
Dual Side |
Tachometer: |
Standard |
Fuel Gauge: |
Standard |
Hour Meter: |
Standard |
Water Safety Switch: |
Standard |
Lifting Bale: |
Standard |
Weight: |
1,950 lbs. |
 |
